XC-01
XICHENG
8421399090
Product description
PP gas scrubber is a purification equipment used to treat industrial waste gas pollution. The size and specifications need to be customized according to the waste gas emissions.
Equipment introduction:
PP gas scrubber is an efficient air pollution control equipment, which is widely used in industrial production. The main function is to absorb and separate the chemical components in the exhaust gas through the gas scrubber, with a purification efficiency of 85%. Processed and made of PP material, it has the characteristics of flame retardant, chemical resistance, light weight and simple operation.
Plastic wet scrubber functional accessories
Structure and working principle
Structure
The structure of PP gas scrubber is summarized as: defogging layer, spray layer, filler layer, transparent window, liquid storage tank, and water pump.
principle
The chemical gas enters the scrubber from the bottom of the scrubber, is sent into the intake space by the blower, and then rises evenly and flows into the packing absorption section. The packing layer is filled with polyhedral balls or Raschig rings to increase the contact neps of the exhaust gas with water. The pollutants in the exhaust gas can chemically react with the water, and the chemical substances will be absorbed by the water. As the absorption liquid of the filler layer flows down to the liquid storage tank, the exhaust gas that is not fully absorbed will rise to the spray layer and will be fully reacted by the high-speed spray water droplets.
Features of this equipment:
1. It is made of PP plastic with high flame-retardant properties.
2. Using high-temperature hot-melt welding technology, easy to install.
3. Various specifications and sizes can be customized to meet the needs of different industries.
Technical Parameter Table :
Air volume (M3/H) | Size (mm) | THK (mm) | Drain outlet (mm) | Water tank size(mm) | Inlet and outlet size (mm) | Pump (KW) | Wind resistance (Pa) |
3000 | 800 | 8 | DN32 | 600*700*H700 | 315 | 0.75 | 500 |
5000 | 1000 | 8 | DN40 | 600*800*H700 | 400 | 1.5 | 500 |
8000 | 1200 | 8 | DN40 | 600*1000*H700 | 500 | 2.2 | 500 |
10000 | 1500 | 10 | DN40 | 700*1000*H700 | 550 | 2.2 | 500 |
12000 | 1600 | 10 | DN50 | 700*1000*H700 | 600 | 3.75 | 500 |
15000 | 1800 | 10 | DN50 | 700*1200*H700 | 650 | 3.75 | 500 |
20000 | 2000 | 10 | DN50 | 700*1200*H700 | 750 | 5.5 | 500 |
25000 | 2200 | 10 | DN50 | 700*1200*H700 | 950 | 5.5 | 600 |
30000 | 2500 | 12 | DN65 | 700*1200*H700 | 1000 | 5.5 | 600 |
35000 | 2700 | 12 | DN65 | 1000*700*H700 | 1100 | 7.5 | 600 |
40000 | 2900 | 12 | DN65 | 1000*700*H700 | 1200 | 7.5 | 600 |
45000 | 3000 | 12 | DN65 | 1000*700*H700 | 1250 | 7.5 | 600 |
1.This form is a common size and we can customize different sizes and requirements according to your needs.
2.The material is polypropylene.
3.Equipment design wind speed 1.8m/s
Product description
PP gas scrubber is a purification equipment used to treat industrial waste gas pollution. The size and specifications need to be customized according to the waste gas emissions.
Equipment introduction:
PP gas scrubber is an efficient air pollution control equipment, which is widely used in industrial production. The main function is to absorb and separate the chemical components in the exhaust gas through the gas scrubber, with a purification efficiency of 85%. Processed and made of PP material, it has the characteristics of flame retardant, chemical resistance, light weight and simple operation.
Plastic wet scrubber functional accessories
Structure and working principle
Structure
The structure of PP gas scrubber is summarized as: defogging layer, spray layer, filler layer, transparent window, liquid storage tank, and water pump.
principle
The chemical gas enters the scrubber from the bottom of the scrubber, is sent into the intake space by the blower, and then rises evenly and flows into the packing absorption section. The packing layer is filled with polyhedral balls or Raschig rings to increase the contact neps of the exhaust gas with water. The pollutants in the exhaust gas can chemically react with the water, and the chemical substances will be absorbed by the water. As the absorption liquid of the filler layer flows down to the liquid storage tank, the exhaust gas that is not fully absorbed will rise to the spray layer and will be fully reacted by the high-speed spray water droplets.
Features of this equipment:
1. It is made of PP plastic with high flame-retardant properties.
2. Using high-temperature hot-melt welding technology, easy to install.
3. Various specifications and sizes can be customized to meet the needs of different industries.
Technical Parameter Table :
Air volume (M3/H) | Size (mm) | THK (mm) | Drain outlet (mm) | Water tank size(mm) | Inlet and outlet size (mm) | Pump (KW) | Wind resistance (Pa) |
3000 | 800 | 8 | DN32 | 600*700*H700 | 315 | 0.75 | 500 |
5000 | 1000 | 8 | DN40 | 600*800*H700 | 400 | 1.5 | 500 |
8000 | 1200 | 8 | DN40 | 600*1000*H700 | 500 | 2.2 | 500 |
10000 | 1500 | 10 | DN40 | 700*1000*H700 | 550 | 2.2 | 500 |
12000 | 1600 | 10 | DN50 | 700*1000*H700 | 600 | 3.75 | 500 |
15000 | 1800 | 10 | DN50 | 700*1200*H700 | 650 | 3.75 | 500 |
20000 | 2000 | 10 | DN50 | 700*1200*H700 | 750 | 5.5 | 500 |
25000 | 2200 | 10 | DN50 | 700*1200*H700 | 950 | 5.5 | 600 |
30000 | 2500 | 12 | DN65 | 700*1200*H700 | 1000 | 5.5 | 600 |
35000 | 2700 | 12 | DN65 | 1000*700*H700 | 1100 | 7.5 | 600 |
40000 | 2900 | 12 | DN65 | 1000*700*H700 | 1200 | 7.5 | 600 |
45000 | 3000 | 12 | DN65 | 1000*700*H700 | 1250 | 7.5 | 600 |
1.This form is a common size and we can customize different sizes and requirements according to your needs.
2.The material is polypropylene.
3.Equipment design wind speed 1.8m/s
