XC-1
Xicheng
8421399090
What is a Nitric acid scrubber?
Nitric acid scrubber are pollution control machines that filter contaminants from air streams and products. When you implement an Nitric acid scrubber in your production line, the reactants neutralize the acid gas and reduce acid gas levels to acceptable levels that are no longer a threat to the environment. Hydrochloric acid fume scrubber systems withstand corrosive atmospheres with low pressure drop and are suitable for the following industries and applications:
landfill
biochemical
Food & Beverage
metal production
steel processing
Wastewater treatment
When polluted air enters a hydrochloric acid fume scrubber system, fine droplets of scrubbing fluid come into contact with the gas. The clean air is sent back to the environment, and the scrubbing liquid can be recycled and reused until a specific saturation point is reached.
Features of this equipment:
1. It is made of PP plastic with high flame-retardant properties.
2. Using high-temperature hot-melt welding technology, easy to install.
3. Various specifications and sizes can be customized to meet the needs of different industries.
Technical Parameter Table :
| Air volume (M3/H) | Size (mm) | THK (mm) | Drain outlet (mm) | Water tank size(mm) | Inlet and outlet size (mm) | Pump (KW) | Wind resistance (Pa) |
| 3000 | 800 | 8 | DN32 | 600*700*H700 | 315 | 0.75 | 500 |
| 5000 | 1000 | 8 | DN40 | 600*800*H700 | 400 | 1.5 | 500 |
| 8000 | 1200 | 8 | DN40 | 600*1000*H700 | 500 | 2.2 | 500 |
| 10000 | 1500 | 10 | DN40 | 700*1000*H700 | 550 | 2.2 | 500 |
| 12000 | 1600 | 10 | DN50 | 700*1000*H700 | 600 | 3.75 | 500 |
| 15000 | 1800 | 10 | DN50 | 700*1200*H700 | 650 | 3.75 | 500 |
| 20000 | 2000 | 10 | DN50 | 700*1200*H700 | 750 | 5.5 | 500 |
| 25000 | 2200 | 10 | DN50 | 700*1200*H700 | 950 | 5.5 | 600 |
| 30000 | 2500 | 12 | DN65 | 700*1200*H700 | 1000 | 5.5 | 600 |
| 35000 | 2700 | 12 | DN65 | 1000*700*H700 | 1100 | 7.5 | 600 |
| 40000 | 2900 | 12 | DN65 | 1000*700*H700 | 1200 | 7.5 | 600 |
| 45000 | 3000 | 12 | DN65 | 1000*700*H700 | 1250 | 7.5 | 600 |
1.This form is a common size and we can customize different sizes and requirements according to your needs.
2.The material is polypropylene.
3.Equipment design wind speed 1.8m/s
What is a Nitric acid scrubber?
Nitric acid scrubber are pollution control machines that filter contaminants from air streams and products. When you implement an Nitric acid scrubber in your production line, the reactants neutralize the acid gas and reduce acid gas levels to acceptable levels that are no longer a threat to the environment. Hydrochloric acid fume scrubber systems withstand corrosive atmospheres with low pressure drop and are suitable for the following industries and applications:
landfill
biochemical
Food & Beverage
metal production
steel processing
Wastewater treatment
When polluted air enters a hydrochloric acid fume scrubber system, fine droplets of scrubbing fluid come into contact with the gas. The clean air is sent back to the environment, and the scrubbing liquid can be recycled and reused until a specific saturation point is reached.
Features of this equipment:
1. It is made of PP plastic with high flame-retardant properties.
2. Using high-temperature hot-melt welding technology, easy to install.
3. Various specifications and sizes can be customized to meet the needs of different industries.
Technical Parameter Table :
| Air volume (M3/H) | Size (mm) | THK (mm) | Drain outlet (mm) | Water tank size(mm) | Inlet and outlet size (mm) | Pump (KW) | Wind resistance (Pa) |
| 3000 | 800 | 8 | DN32 | 600*700*H700 | 315 | 0.75 | 500 |
| 5000 | 1000 | 8 | DN40 | 600*800*H700 | 400 | 1.5 | 500 |
| 8000 | 1200 | 8 | DN40 | 600*1000*H700 | 500 | 2.2 | 500 |
| 10000 | 1500 | 10 | DN40 | 700*1000*H700 | 550 | 2.2 | 500 |
| 12000 | 1600 | 10 | DN50 | 700*1000*H700 | 600 | 3.75 | 500 |
| 15000 | 1800 | 10 | DN50 | 700*1200*H700 | 650 | 3.75 | 500 |
| 20000 | 2000 | 10 | DN50 | 700*1200*H700 | 750 | 5.5 | 500 |
| 25000 | 2200 | 10 | DN50 | 700*1200*H700 | 950 | 5.5 | 600 |
| 30000 | 2500 | 12 | DN65 | 700*1200*H700 | 1000 | 5.5 | 600 |
| 35000 | 2700 | 12 | DN65 | 1000*700*H700 | 1100 | 7.5 | 600 |
| 40000 | 2900 | 12 | DN65 | 1000*700*H700 | 1200 | 7.5 | 600 |
| 45000 | 3000 | 12 | DN65 | 1000*700*H700 | 1250 | 7.5 | 600 |
1.This form is a common size and we can customize different sizes and requirements according to your needs.
2.The material is polypropylene.
3.Equipment design wind speed 1.8m/s
