Application and design parameters of activated carbon tower

Views:18     Author:China Xicheng     Publish Time: 2021-07-22      Origin:China Xicheng

The activated carbon adsorption tower is the best purification equipment for dealing with organic waste gas and odor treatment. Activated carbon adsorption is an effective way to remove the odor of water, natural and synthetic dissolved organic matter, micro polluting substances and so on.


 Table parameters

Activated carbon tower common specification size
   Air volume Type Specification/mm With activated     carbon Thickness Through area
1500-2500 2layers1side 1050*870*1000 100kg 10mm 0.64 (M2)
2500-3500 3layers1side 1150*870*1700 125kg 10mm 0.96(M2)
3500-5000 2layers1side 1550*870*1000 175kg 10mm 1.28 (M2)
5000-7000 3layers1side 1600*870*1700 275kg 10mm 1.92 (M2)
7000-10000 3layers1side 2150*870*1700 400kg 10mm 2.88 (M2)
10000-14000 3layers2side 1600*1730*1700 525kg 10mm 3.84(M2)
14000-18000 4layers2side 1800*1730*2000 700kg 10mm 5.12 (M2)
18000-22000 3layers2side 2150*1730*1700 775kg 10mm 5.76(M2)
22000-28000 3layers2side 2650*1730*700 1050kg 10mm 7.68(M2)
28000-35000 4layers2side 2900*1730*2000 1400kg 12mm 10.24(M2)
35000-45000 4layers2side 3500*1730*2400 1725kg 12mm 12.8(M2)
45000-55000 4layers2side 4000*1730*2400 2075KG 12mm 15.36(M2)
55000-6000 5layers2side 4000*1730*2900 2600kg 12mm

19.2(M2)


Activated carbon adsorption box industry application


Activated carbon adsorption box is widely used in the end treatment of industrial organic waste gas and laboratory exhaust air purification, and the purification effect is good. After the gas enters the activated carbon adsorption box through the pipeline, a diffusion process occurs between the two different phase interfaces. After the diffusion is completed, the gas is sucked out by the fan and discharged.

Activated carbon tower usage scenarios

The activated carbon adsorption box is mainly used for the treatment of organic waste gas with high air volume and low concentration; the activated carbon adsorbent can treat and purify a variety of organic and inorganic pollutants: benzene, ketones, alcohols, ethers, alkanes and their mixed organic waste gas, Acidic waste gas, alkaline waste gas; mainly used in pharmaceutical, smelting, chemical, machinery, electronics, electrical appliances, painting, shoemaking, rubber, plastic, printing and environmental protection desulfurization, deodorization and harmful waste gas generated in various industrial production workshops Purification treatment. A few typical industry applications of activated carbon adsorption boxes are listed below.


What is in the activated carbon adsorption box

The activated carbon adsorption box is filled with granular activated carbon. Activated carbon is a very small carbon particle with a large surface area, and there are finer pores in the carbon particle-capillary. This capillary has a strong adsorption capacity, Due to the large surface area of the carbon particles, it can fully contact the gas (impurities). When these gases (impurities) hit the capillary, they are adsorbed and play a purification role. The essence of activated carbon adsorption is to use the characteristics of activated carbon adsorption to adsorb the organic solvents in the low-concentration and high-volume exhaust gas into the activated carbon. The activated carbon adsorption method is mainly used for the removal of low-concentration gaseous pollutants.


How does the activated carbon adsorption box work?

When the exhaust gas is powered by the fan, the negative pressure enters the adsorption box and then enters the activated carbon adsorption layer. Due to the unbalanced and unsaturated molecular attraction or chemical bonding force on the surface of the activated carbon adsorbent, when the surface of the activated carbon adsorbent contacts the gas, It can attract gas molecules, make them concentrate and keep them on the surface of activated carbon. This phenomenon is called adsorption. Using the adsorption capacity of the activated carbon adsorbent surface, the exhaust gas is in contact with the porous activated carbon adsorbent on the large surface, and the pollutants in the exhaust gas are adsorbed on the surface of the activated carbon to separate it from the gas mixture, and the purified gas is discharged at high altitude.
